LZM WaterFine Coil Baking Paint
I Product overview
◆Category: This product is one-component colored baking paint with high-grade resin as film material;
◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;
◆Characteristics:
※Fountain pen traces can be wiped off;
※Water is the disperse medium of this product, no fire point at normal temperature, combustion and detonation is unlikely to occur;
※Fine adhesion, weatherability, protection and decoration performance;
※Volatile water is less than organic solvent, so floor space is greater than oily paint under the same thickness for construction;
※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union.
III Technical data (typical data)
|
Item |
Indicator |
|
Color and appearance |
White thick liquid |
|
Fineness |
≤20μm |
|
PH value |
8.0~9.0 |
|
Viscosity (paint-4cup) |
≥160s |
|
Solid content (120°C /2 hour) |
≥60% |
|
Gloss (60° photometer) |
≥80 |
|
Adhesion (Circle method) |
≤class 1 |
|
Impact strength |
≥50 kg.cm |
|
Pencil hardness |
≥2H |
|
Flexibility |
≤1 mm |
|
Resistance to waterproof whiteboard |
Easy to wipe off |
IV Construction for reference
◆Surface treatment: wipe off the impurity, for example, floating dust, rust, oil stain, etc. to keep the surface clean and dry;
◆Form of construction work: roll coating;
◆Thinner: purified water or clean tap water;
◆Dilution ratio: add water by 5%~10% of the paint weight, or adjust as the case may be;
◆Applicable viscosity: roll 60~90s (paint-4cup, 23±2°C);
◆Type of drying: baking at a constant temperature of 210±2°C for 70~90s;
◆Coating area: 1200m2~1400 m2 (thickness of single layer dry film: 15μm ~20μm). The actual area is related to the specific construction thickness (dry film).
VII Attentions
◆Difference in the level of processing metal substrate is referred to final effect and barrier property of the film coating;
◆Keep the product in a cool and ventilate place (0°C~45°C). The validity is 1 year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.
VI Packing and shipping
◆Packing: 70kg/barrel;
◆Shipping: transport as non-hazardous goods.
